| ROPE DIAMETER (INCHES) | CERTEX Cat. Ref. No. | SINGLE LEG | ||
|---|---|---|---|---|
| VERTICAL | CHOKER | VERTICAL BASKET | ||
| 1/8 | CX02-0225 | 1.1 | 0.95 | 2.2 |
| 3/16 | CX02-0226 | 2.2 | 1.9 | 4.3 |
| 1/4 | CX02-0227 | 3.8 | 3.3 | 7.6 |
| 5/16 | CX02-0228 | 5.5 | 4.8 | 11 |
| 3/8 | CX02-0229 | 8 | 7 | 16 |
| 7/16 | CX02-0230 | 11 | 10 | 23 |
| 1/2 | CX02-0231 | 15 | 13 | 30 |
| 9/16 | CX02-0232 | 19 | 16 | 38 |
| 5/8 | CX02-0233 | 23 | 20 | 46 |
| 3/4 | CX02-0234 | 33 | 29 | 36 |
| 7/8 | CX02-0235 | 45 | 39 | 89 |
| 1 | CX02-0236 | 58 | 51 | 116 |
| 1 1/8 | CX02-0237 | 73 | 64 | 146 |
| 1 1/4 | CX02-0238 | 89 | 78 | 179 |
| 1 3/8 | CX02-0239 | 108 | 94 | 215 |
| 1 1/2 | CX02-0240 | 127 | 111 | 255 |
| 1 5/8 | CX02-0241 | 148 | 130 | 296 |
| 1 3/4 | CX02-0242 | 171 | 150 | 343 |
| 1 7/8 | CX02-0243 | 195 | 171 | 390 |
| 2 | CX02-0244 | 222 | 194 | 443 |
RATED CAPACITIES BASKET HITCH BASED ON D/d RATIO OF 25 TIMES THE COMPONENT ROPE DIAMETER
RATED CAPACITIES BASED ON PIN DIAMETER NO LARGER THAN NATURAL EYE WIDTH OR LESS THAN THE NOMINAL SLING DIAMETER
RATED CAPACITIES BASED ON DESIGN FACTOR OF 5
HORIZONTAL SLING ANGLES LESS THAN 30 DEGREES SHALL NOT BE USED
Rated Capacities shown for 1/8” through 3/8” apply only to 7×19 galvanized wire rope.
Rated Capacities shown for 3/8” apply only to 6×19, and 6×37 classification wire rope.
