Caldwell 3t Adjustable Height & Span Gantry Model K90-3

Caldwell 3t Adjustable Height & Span Gantry Model K90-3

Features:

  • Adjustable span standard on 10′-16′ spans through 5 tons
  • Bolted connections on spans of 20′-24′ and all 8 ton units
  • Heavy duty supported leg design
  • Balanced design allows for easy rolling, even under load
  • Conforms to AISC, OSHA, and CMAA specifications
  • Simple bolt together construction
  • Easy setup and maintenance
  • 4-wheel swivel casters standard
  • Height and span adjustability
  • Height adjustable down from maximum in 12″ incremements

EMAIL PAGE

EMAIL PAGE


VIEW IN CATALOG

VIEW IN CATALOG


WARNINGS & CAUTIONS

WARNINGS & CAUTIONS

Model Number Capacity  (tons) Beam Ht (in.) Caster Dia (in.) Clamp Con Length (ft.) Weight (lbs.) Flange W (in.) Ht Under Beam (ft.) Ht Under Boom (ft.) Thickness (in.) In Stock Price
K90-3-10/10 3 10 8 10 1175 4.7 7 10 5.5 ❌ $
K90-3-10/12 3 10 8 12 1200 4.7 7 10 5.5 ❌ $
K90-3-10/14 3 10 8 14 1275 4.7 7 10 5.5 ❌ $
K90-3-10/16 3 12 8 16 1425 5 7 10 5.5 ❌ $
K90-3-10/20 3 15 8 19 1800 5.5 10 10 5.5 ❌ $
K90-3-10/24 3 18 8 23 2300 6 10 10 5.5 ❌ $
K90-3-12/10 3 10 8 10 1300 4.7 8 12 6.5 ❌ $
K90-3-12/12 3 10 8 12 1375 4.7 8 12 6.5 ❌ $
K90-3-12/14 3 10 8 14 1400 4.7 8 12 6.5 ❌ $
K90-3-12/16 3 12 8 16 1575 5 8 12 6.5 ❌ $
K90-3-12/20 3 15 8 19 1975 5.5 12 12 6.5 ❌ $
K90-3-12/24 3 18 8 23 2450 6 12 12 6.5 ❌ $
K90-3-14/10 3 10 8 10 1400 4.7 9 14 7.5 ❌ $
K90-3-14/12 3 10 8 12 1475 4.7 9 14 7.5 ❌ $
K90-3-14/14 3 10 8 14 1525 4.7 9 14 7.5 ❌ $
K90-3-14/16 3 12 8 16 1675 5 9 14 7.5 ❌ $
K90-3-14/20 3 15 8 19 2075 5.5 14 14 7.5 ❌ $
K90-3-14/24 3 18 8 23 2550 6 14 14 7.5 ❌ $
K90-3-16/10 3 10 8 10 1500 4.7 10 16 7.5 ❌ $
K90-3-16/12 3 10 8 12 1550 4.7 10 16 7.5 ❌ $
K90-3-16/14 3 10 8 14 1600 4.7 10 16 7.5 ❌ $
K90-3-16/16 3 12 8 16 1750 5 10 16 7.5 ❌ $
K90-3-16/20 3 15 8 19 2150 5.5 16 16 7.5 ❌ $
K90-3-16/24 3 18 8 23 2625 6 16 16 7.5 ❌ $
K90-3-7/10 3 10 8 10 1000 4.7 5 7 4 ❌ $
K90-3-7/12 3 10 8 12 1050 4.7 5 7 4 ❌ $
K90-3-7/14 3 10 8 14 1100 4.7 5 7 4 ❌ $
K90-3-7/16 3 12 8 16 1250 5 5 7 4 ❌ $
K90-3-7/20 3 15 8 19 1675 5.5 7 7 4 ❌ $
K90-3-7/24 3 18 8 23 2125 6 7 7 4 ❌ $
K90-3-9/10 3 10 8 10 1100 4.7 6 9 5 ❌ $
K90-3-9/12 3 10 8 12 1175 4.7 6 9 5 ❌ $
K90-3-9/14 3 10 8 14 1225 4.7 6 9 5 ❌ $
K90-3-9/16 3 12 8 16 1375 5 6 9 5 ❌ $
K90-3-9/20 3 15 8 19 1750 5.5 9 9 5 ❌ $
K90-3-9/24 3 18 8 23 2250 6 9 9 5 ❌ $
