Applications:
As temporary repair link, use one size larger than Proof coil chain (Grade 30)
with which it is to be used. Also used to couple light attachments.
Packaging:
1/4” thru 5/8” zinc-plated, packed 10 per carton. All other bulk.
Applications:
As temporary repair link, use one size larger than Proof coil chain (Grade 30)
with which it is to be used. Also used to couple light attachments.
Packaging:
1/4” thru 5/8” zinc-plated, packed 10 per carton. All other bulk.
Trade Size Inches | Zinc-Plated Bulk (Ea.) | Self-Colored Carton (10) | Inside Length Inches | Inside Width Inches | Weight per 100 Pieces Pounds | Working Load Limit* Pounds | ||||
CERTEX Cat. Ref. No | Columbus McKinnon Code No | UPC Code | CERTEX Cat. Ref. No. | Columbus McKinnon Code No. | UPC Code | |||||
3/16 | CX06-0895 | 50091 | 29060 | — | — | — | 15/16 | 5/16 | 3 | 525 |
1/4 | CX06-0896 | 50191 | 29062 | CX06-0902 | 673104 | 34175 | 1 | 3/8 | 6 | 925 |
5/16 | CX06-0897 | 50291 | 29067 | CX06-0903 | 673105 | 34176 | 1 3/16 | 7/16 | 10 | 1,450 |
3/8 | CX06-0898 | 50391 | 29072 | CX06-0904 | 673106 | 34177 | 1 5/16 | 1/2 | 18 | 2,110 |
7/16 | CX06-0899 | 50491 | 29077 | CX06-0905 | 673107 | 34178 | 1 1/2 | 9/16 | 26 | 2,850 |
1/2 | CX06-0900 | 50591 | 29082 | CX06-0906 | 673108 | 34179 | 1 9/16 | 3/4 | 38 | 3,750 |
5/8 | CX06-0901 | 50691 | 29087 | CX06-0907 | 673110 | 34180 | 2 1/8 | 7/8 | 78 | 5,850 |
Low carbon steel, self-colored or zinc-plated finish.
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
