GOLD-TIP® Eye-Eye Long Barrel Binder 20″

GOLD-TIP® Eye-Eye Long Barrel Binder 20″
  • All load-bearing fittings are forged
  • Quenched and tempered
  • Fittings are yellow zinc plated
  • Handle and barrel are powder coated
  • Heavy duty swaged & tapered tube body
  • One piece handle
  • Load binders are DOT compliant
  • Longer barrel than standard load binders

EMAIL PAGE

EMAIL PAGE


WARNINGS & CAUTIONS

WARNINGS & CAUTIONS

STOCK NUMBER TAKE-UP BARREL LENGTH HANDLE
LENGTH		 SCREW DIAMETER EYE
INSIDE
DIAMETER		 BEARING TO BEARING (CLOSED TO OPEN) WORKING LOAD LIMIT (LBS.) MINIMUM BREAKING STRENGTH (LBS.) WEIGHT (LBS.)
GT1300EE20 18″ 20″ 15.5″ 1″ 1″ 25″ – 43″ 13,000 26,000 15

WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
