| STOCK NUMBER | TAKE-UP | BARREL LENGTH | HANDLE LENGTH |
SCREW DIAMETER | JAW THROAT OPENING |
BEARING TO BEARING (CLOSED TO OPEN) | WORKING LOAD LIMIT (LBS.) | MINIMUM BREAKING STRENGTH (LBS.) | WEIGHT (LBS.) |
|---|---|---|---|---|---|---|---|---|---|
| GT9200JJ24 | 22″ | 24″ | 15.5″ | 1″ | 1 1/4″ | 30″ – 52″ | 9,200 | 18,400 | 21 |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
