5 Tons Section Only
| CERTEX Cat. Ref. No. | McKisset Model No | Inquiry Stock No. | Working Load Limit (tons) | No. of Sheaves | Sheave Diam. (in.) | Blocks with Hanger and Shackle – Dimensions | Weight Each (lbs.) | |||||||||||
| A | E | F | G | H | I | S | T | U | V | W | X | |||||||
| CX13-0812 | C5S6BS | 2103000 | 5 | 1 | 6 | 18.56 | 2.28 | 6.12 | — | — | — | 3.81 | 2.56 | 1.14 | .88 | .97 | — | 25 |
| CX13-0813 | C5S8BS | 2103002 | 5 | 1 | 8 | 20.44 | 2.28 | 8.12 | — | — | — | 3.81 | 2.56 | 1.14 | .88 | .97 | — | 37 |
| CX13-0814 | C5D6BS | 2103010 | 5 | 2 | 6 | 21.19 | 4.31 | 6.12 | .63 | .69 | .84 | 3.81 | 2.56 | 1.14 | .88 | .97 | 2.03 | 40 |
| CX13-0815 | C5D8BS | 2103012 | 5 | 2 | 8 | 23.06 | 4.31 | 8.12 | .63 | .69 | .84 | 3.81 | 2.56 | 1.14 | .88 | .97 | 2.03 | 61 |
| CX13-0816 | C5T6BS | 2103020 | 5 | 3 | 6 | 21.19 | 6.34 | 6.12 | .63 | .69 | .84 | 3.81 | 2.56 | 1.14 | .88 | .97 | 2.03 | 54 |
| CX13-0817 | C5T8BS | 2103022 | 5 | 3 | 8 | 23.06 | 6.34 | 8.12 | .63 | .69 | .84 | 3.81 | 2.56 | 1.14 | .88 | .97 | 2.03 | 84 |
Other Sizes Available by Request.
Options Available
