APPLICATIONS
FEATURES
| ROPE SIZE DIAMETER | STOCK NUMBER | DESCRIPTION | REEL LENGTH | COLOR | WORKING LOAD LIMIT (lbs.) | MINIMUM BREAKING STRENGTH (lbs.) |
|---|---|---|---|---|---|---|
| 3/16” | NYLON187X600 | Nylon Twisted Rope | 600′ | White | 200 | 1,000 |
| 1/4” | NYLON250X600 | Nylon Twisted Rope | 600′ | White | 330 | 1,650 |
| 5/16” | NYLON312X600 | Nylon Twisted Rope | 600′ | White | 510 | 2,550 |
| 3/8” | NYLON375X600 | Nylon Twisted Rope | 600′ | White | 740 | 3,700 |
| 1/2” | NYLON500X600 | Nylon Twisted Rope | 600′ | White | 1,280 | 6,400 |
| 5/8” | NYLON625X600 | Nylon Twisted Rope | 600′ | White | 2,080 | 10,400 |
| 3/4” | NYLON750X600 | Nylon Twisted Rope | 600′ | White | 2,840 | 14,200 |
| 7/8” | NYLON875X600 | Nylon Twisted Rope | 600′ | White | 4,000 | 20,000 |
| 1” | NYLON100X600 | Nylon Twisted Rope | 600′ | White | 5,000 | 25,000 |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
