OVERVIEW
APPLICATIONS
A very flexible rope with a core in a special design avoiding crossovers between the strands of core and preventing internal rope destruction. Hoist rope for mobile cranes, electrical hoists and other applications, where rotation resistant ropes are required.
| Diameter Range | 7–50 | 50,8–72 |
| RCN | 23–2 | 23–2 |
| Number of Outer Strands | 16 | 16 |
| Number of Wires | 245 | 349 |
| Number of Outer Load Bearing Wires | 112 | 112 |
| Average Fill Factor | 0,653 | |
| Average Nominal Metallic Area Factor C | 0,513 | |
| Average Spin Factor | 0,76 | |
| nominal diameter | weight | minimum breaking force | |||||||||
| 1770 N/mm² | 1960 N/mm² | ||||||||||
| mm | inch | kg/m | lb/ft | kN | t [metric] | lbs | t [2000 lbs] | kN | t [metric] | lbs | t [2000 lbs] |
| 7 | 0,22 | 0,15 | 34,1 | 3,48 | 7.666 | 3,83 | 37,8 | 3,85 | 8.498 | 4,25 | |
| 8 | 5/16 | 0,29 | 0,19 | 44,5 | 4,54 | 10.004 | 5,00 | 49,3 | 5,03 | 11.083 | 5,54 |
| 9 | 0,37 | 0,25 | 55,4 | 5,65 | 12.454 | 6,23 | 61,3 | 6,25 | 13.781 | 6,89 | |
| 10 | 0,46 | 0,31 | 69,2 | 7,06 | 15.557 | 7,78 | 76,6 | 7,81 | 17.220 | 8,61 | |
| 11 | 7/16 | 0,55 | 0,37 | 83,1 | 8,47 | 18.682 | 9,34 | 92,1 | 9,39 | 20.705 | 10,35 |
| 12 | 0,66 | 0,44 | 99,9 | 10,19 | 22.458 | 11,23 | 114,1 | 11,29 | 24.886 | 12,44 | |
| 1/2 | 0,72 | 0,48 | 111,7 | 11,39 | 25.111 | 11,23 | 114,1 | 11,64 | 25.651 | 12,83 | |
| 13 | 0,77 | 0,52 | 117,3 | 11,96 | 26.370 | 13,19 | 129,8 | 13,24 | 29.180 | 14,59 | |
| 14 | 0,89 | 0,60 | 135,9 | 13,86 | 30.552 | 15,28 | 150,5 | 15,35 | 33.834 | 16,92 | |
| 15 | 1,04 | 0,70 | 156,3 | 15,94 | 35.138 | 17,57 | 173,0 | 17,64 | 38.892 | 19,45 | |
| 16 | 5/8 | 1,17 | 0,79 | 178,1 | 18,16 | 40.038 | 20,02 | 197,2 | 20,11 | 44.332 | 22,17 |
| 17 | 1,31 | 0,88 | 200,1 | 20,40 | 44.984 | 22,49 | 221,6 | 22,60 | 49.818 | 24,91 | |
| 18 | 1,47 | 0,99 | 222,6 | 22,70 | 50.042 | 25,02 | 246,5 | 25,14 | 55.415 | 27,71 | |
| 19 | 3/4 | 1,66 | 1,12 | 250,9 | 25,58 | 56.405 | 28,20 | 277,8 | 28,33 | 62.452 | 31,23 |
| 20 | 1,82 | 1,23 | 277,7 | 28,32 | 62.429 | 31,21 | 307,5 | 31,36 | 69.129 | 34,56 | |
| 21 | 2,02 | 1,35 | 306,3 | 31,23 | 68.859 | 34,43 | 339,2 | 34,59 | 76.255 | 38,13 | |
| 22 | 2,19 | 1,47 | 337,0 | 34,36 | 75.761 | 37,88 | 373,2 | 38,06 | 83.899 | 41,95 | |
| 7/8 | 2,25 | 1,51 | 337,0 | 34,36 | 75.761 | 37,88 | 373,2 | 38,06 | 83.899 | 41,95 | |
| 23 | 2,41 | 1,62 | 366,5 | 37,37 | 82.392 | 41,20 | 405,9 | 41,39 | 91.250 | 45,62 | |
| 24 | 2,63 | 1,77 | 400,5 | 40,84 | 90.036 | 45,02 | 443,5 | 45,22 | 99.703 | 49,85 | |
| 25 | 2,83 | 1,90 | 431,9 | 44,04 | 97.095 | 48,55 | 478,3 | 48,77 | 107.526 | 53,76 | |
| 1 | 2,97 | 2,00 | 445,8 | 45,46 | 100.220 | 50,11 | 493,7 | 50,34 | 110.988 | 55,49 | |
| 26 | 3,08 | 2,07 | 468,2 | 47,74 | 105.256 | 52,63 | 519,5 | 52,97 | 116.788 | 58,39 | |
| 27 | 3,30 | 2,22 | 508,3 | 51,83 | 114.270 | 57,14 | 562,9 | 57,40 | 126.545 | 63,27 | |
| 28 | 3,56 | 2,39 | 548,8 | 55,96 | 123.375 | 61,69 | 607,7 | 61,97 | 136.616 | 68,31 | |
| 1 1/8 | 3,76 | 2,52 | 571,6 | 58,29 | 128.501 | 64,25 | 632,9 | 64,54 | 142.282 | 71,14 | |
| 29 | 3,83 | 2,57 | 585,8 | 59,74 | 131.693 | 65,85 | 648,6 | 66,14 | 145.811 | 72,91 | |
| 30 | 4,11 | 2,76 | 627,1 | 63,95 | 140.978 | 70,49 | 694,4 | 70,81 | 156.107 | 78,05 | |
| 31 | 4,34 | 2,91 | 665,6 | 67,87 | 149.633 | 74,82 | 736,9 | 75,14 | 165.662 | 82,83 | |
| 32 | 1 1/4 | 4,64 | 3,11 | 710,5 | 72,45 | 159.727 | 79,86 | 786,7 | 80,22 | 176.857 | 88,43 |
| 33 | 4,94 | 3,32 | 753,1 | 76,80 | 169.304 | 84,65 | 833,9 | 85,04 | 187.468 | 93,73 | |
| 34 | 5,23 | 3,52 | 803,9 | 81,98 | 180.724 | 90,36 | 890,2 | 90,78 | 200.125 | 100,06 | |
| 35 | 1 3/8 | 5,61 | 3,77 | 848,2 | 86,49 | 190.683 | 95,34 | 939,3 | 95,78 | 211.163 | 105,58 |
| 36 | 5,86 | 3,93 | 906,1 | 92,40 | 203.699 | 101,85 | 1.003,4 | 102,32 | 225.573 | 112,79 | |
| 38 | 1 1/2 | 6,61 | 4,44 | 1.005,5 | 102,53 | 226.045 | 113,02 | 1.113,5 | 113,55 | 250.325 | 125,16 |
| 40 | 7,24 | 4,87 | 1.111,9 | 113,38 | 249.965 | 124,98 | 1.231,3 | 125,56 | 276.807 | 138,40 | |
| 1 5/8 | 7,71 | 5,18 | 1.183,9 | 120,73 | 266.154 | 133,08 | 1.311,0 | 133,69 | 294.735 | 147,37 | |
| 42 | 8,00 | 5,38 | 1.234,1 | 125,84 | 277.437 | 138,72 | 1.366,6 | 139,36 | 307.224 | 153,61 | |
| 44 | 8,80 | 5,91 | 1.352,7 | 137,94 | 304.099 | 152,05 | 1.497,9 | 152,74 | 336.741 | 168,37 | |
| 1 3/4 | 8,77 | 5,90 | 1.380,5 | 140,77 | 310.349 | 155,17 | 1.528,7 | 155,89 | 343.665 | 171,83 | |
| 46 | 9,62 | 6,46 | 1.473,9 | 150,30 | 331.346 | 165,67 | 1.632,1 | 166,43 | 366.911 | 183,46 | |
| 48 | 1 7/8 | 10,50 | 7,06 | 1.608,1 | 163,98 | 361.515 | 180,76 | 1.780,7 | 181,58 | 400.317 | 200,16 |
| 50 | 11,39 | 7,65 | 1.740,0 | 177,43 | 391.167 | 195,58 | 1.926,7 | 196,47 | 433.139 | 216,57 | |
| 2 | 11,63 | 7,82 | 1.796,1 | 183,15 | 403.779 | 201,89 | 1.988,8 | 202,80 | 447.100 | 223,55 | |
| 52 | 12,38 | 8,32 | 1.832,5 | 186,86 | 411.962 | 205,98 | 2.029,2 | 206,92 | 456.182 | 228,09 | |
| 54 | 2 1/8 | 13,36 | 8,98 | 1.976,4 | 201,54 | 444.312 | 222,16 | 2.188,5 | 223,17 | 491.994 | 246,00 |
| 56 | 14,33 | 9,63 | 2.141,3 | 218,35 | 481.383 | 240,69 | 2.371,1 | 241,79 | 533.044 | 266,52 | |
| 2 1/4 | 14,68 | 9,87 | 2.230,1 | 227,41 | 501.346 | 250,67 | 2.469,5 | 251,82 | 555.166 | 277,58 | |
| 58 | 15,41 | 10,35 | 2.285,4 | 233,05 | 513.778 | 256,89 | 2.530,8 | 258,07 | 568.946 | 284,47 | |
| 60 | 16,53 | 11,11 | 2.455,9 | 250,43 | 552.108 | 276,05 | 2.719,5 | 277,31 | 611.368 | 305,68 | |
| 2 3/8 | 16,71 | 11,23 | 2.482,6 | 253,16 | 558.106 | 279,05 | 2.749,0 | 280,33 | 618.009 | 309,00 | |
| 62 | 17,65 | 11,86 | 2.623,1 | 267,48 | 589.696 | 294,85 | 2.904,7 | 296,20 | 653.002 | 326,50 | |
| 64 | 2 1/2 | 18,81 | 12,64 | 2.799,3 | 285,45 | 629.308 | 314,65 | 3.099,8 | 316,09 | 696.863 | 348,43 |
| 66 | 20,04 | 13,47 | 2.978,8 | 303,76 | 669.661 | 334,83 | 3.298,5 | 336,36 | 741.532 | 370,77 | |
| 2 5/8 | 20,45 | 13,74 | 3.040,0 | 310,00 | 683.428 | 341,71 | 3.366,3 | 343,27 | 756.777 | 378,39 | |
| 68 | 21,31 | 14,32 | 3.173,9 | 323,65 | 713.521 | 356,76 | 3.514,6 | 358,39 | 790.113 | 395,06 | |
| 70 | 2 3/4 | 22,58 | 15,18 | 3.336,5 | 340,23 | 750.075 | 375,04 | 3.694,7 | 376,76 | 830.601 | 415,30 |
| 72 | 23,95 | 16,10 | 3.545,6 | 361,55 | 797.082 | 398,54 | 3.926,2 | 400,37 | 882.645 | 441,32 | |
WARNING: Prop 65: Products supplied by CERTEX USA may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
